World Class water sports performance is yours with the incredibly user-friendly Stargazer – Wake Edition System from PerfectPass.
The same pull and benefits enjoyed by the Pro Riders for years is now available to all boat owners.
Driving made easy and pulling power designed to enhance your riding is what the Stargazer – Wake Edition is all about. Accurately driving today’s boats at slow speeds is a challenge if not a superhuman task for the best of drivers.
With PerfectPass, the driver simply pre-selects the speed on the In-Dash Display, pull up the rider as usual and when the boat speed reaches the set speed PerfectPass takes over. It’s that simple!
All systems come with the new multi line graphics Display Gauge.
A larger digital speed reading, on screen tachometer and you can personalize the screen with Riders Name & Speed.
Up to eight names can be stored on the “Name List”.
This new platform uses high speed GPS technology and engine rpm for all control functions. (The paddle wheel is no longer required)
Features of Star Gazer Wake Edition
Three operating modes including the new Slalom Mode.
The large digital GPS speedometer is accurate to 1/10 mph and calibration is never required
Graphics In-Dash Display Gauge to match your boat perfectly.
"Personalized Screen" will show riders name & preferred speed;
Adjustable pull characteristics so you can tailor the pull to suit your boat, ballast & riding style;
Now designed for most late model boats
What Engines can be fitted with Star Gazer?
Inboard: Indmar - PCM - Mercruiser
Centre Mount or V-Drive - DBW (Drive By Wire) Late model boats < 2011 models
All Mechanical (Traditional Cable) Early Model boats
Carburetor or EFI - V6 or V8 Engines
Must have hand throttle Does not suit foot throttles
Stern Drive: Volvo Penta Mercruiser >190 hp 4.3l
What’s involved with the installation works?
When the package arrives from Cassell Marine, all components are included together with a detailed installation instruction booklet showing the install process step by step and all of the necessary parts and fittings.
The instruction booklet has been prepared so that the boat owner (with some mechanical / general experience) can install the system themselves. Alternatively, the Cassell Marine service department can install your system.
The main works are;
Remove existing Speedo unit , Replace with new unit and provide power
Run cables to engine area ,Attach servo motor to engine area , Attach cables to engine
(As this new system relies on only GPS technology, there is no need for paddle wheel to be installed nor hole to be drilled through the hull)
PerfectPass manufactures custom In-Dash Display Gauges in a variety of styles and colors to match most late model boats. Below is just a sampling of our most popular models
Pro Series will suit Early model Malibu / Lewis / Skicraft / Camero / Rolco / Matrix & most Australian ski boats as well as US made boats Bayliner / Fourwinns / Sea Ray / Cobalt / Maxum / Stingray / Crownline / Glastron etc
